GLT800×1200Heavy‑Duty Hammer Mill

PRODUCT PARAMETERS

  • Model: GLT80×120 Hammer Mill
  • Main Motor Power: 132kW
  • Fan Motor Power: 37kW
  • Actual Capacity: 4.0‑6.0 Ton/Hour
  • Hammer Quantity: 120 pcs
  • Output Particle Size: 6-14 mm (change screens)
  • Dimension(L×W×H): 2350×1250×1700 mm
  • Power Supply: 380V/50Hz, customizable
  • Standard Accessories: Main host, electric control cabinet
Description
FAQs
Request A Quote

Description

Product Overview

GLT800×1200 heavy‑duty hammer mill is widened‑rotor version of 80‑series with large feeding inlet and high throughput. Perfect supporting host for 850 large pellet mill for 24‑hour full‑load production in big biomass factories. Powerful crushing performance for high‑moisture & high‑fiber palm and straw materials. Thickened steel‑plate welded frame for strong anti‑impact performance, ideal for large overseas investment projects.

Technical Specifications

表格

ItemGLT800×1200
ModelGLT800×1200 Hammer Mill
Main Motor Power132kW
Actual Capacity4.0‑6.0 Ton/Hour
Hammer Quantity120 pcs
Output Particle Size6-14 mm (change screens)
Dimension(L×W×H)2350×1250×1700 mm
Power Supply380V/50Hz, customizable
Standard AccessoriesMain host, electric control cabinet

Application: Large biomass pellet plant, complete production line for palm mill, mass straw‑treatment project, supporting 850 pellet host.

FAQs

Our pellet mill processes wood sawdust, wood chips, straw, rice husk, peanut shell, bamboo dust, fruit tree branches and other biomass waste. Different dies are available for various feedstock. Raw materials should be crushed to 3‑5 mm with moisture 10‑15% for premium‑quality pellets. A dryer is required for high‑moisture materials.

o prepare an accurate proposal, please provide:

1.raw material type; 2. target output per hour; 3.raw‑material moisture; 4. local voltage & frequency; 5. workshop size; 6.budget.

Our engineers supply equipment list, layout drawing and budget for free. Material test is available at our factory.

Yes. Motors can be customized to match local voltage & frequency (380V/415V/440V, 50Hz/60Hz) for different countries.

We are direct manufacturer with full‑set machining & assembly workshop. Factory visits are warmly welcome; virtual video tour is available. Material test run is supported.

Common wear parts are in stock and can be shipped together with main machine. For separate orders: air freight 7‑15 days, sea freight 30‑45 days.
