Big‑Bag Filling Machine (Ton‑Bag Packing Scale)

Product Overview

Our big‑bag filling machine, also known as jumbo bag / FIBC ton‑bag packing scale, is specialized large‑volume packaging equipment matched with biomass pellet production lines. After cooling process, finished wood pellets, straw pellets and agro‑forestry pellets can be quantitatively filled into 500‑1000 kg FIBC jumbo bags. It solves low‑efficiency manual bulk packaging problem for large‑tonnage pellet factories, greatly reducing labor cost and improving packaging consistency.

Adopting gross‑weight weighing structure and dual‑speed feeding system (fast feeding + fine feeding), this ton‑bag filler realizes stable weighing accuracy. Equipped with sealed dust‑proof filling spout, it effectively suppresses dust overflow during pellet filling. It can work independently or connect seamlessly with our pellet mill, counterflow pellet cooler and conveyor system for full‑auto pellet production line.

Working Principle

1. Operators hang empty FIBC jumbo bags onto four bag hooks and clamp the bag mouth tightly with pneumatic clamping mechanism to prevent dust leakage.
2. Under PLC touch‑screen control, materials flow into the bag via fast‑slow dual feeding mode. High‑precision load cells monitor real‑time weight.
3. When reaching preset target weight, feeding stops automatically. After material settling, the hooks release automatically.
4. Filled ton‑bag drops onto pallet or roller conveyor, ready for forklift transportation and warehouse storage.

Core Advantages

✅ High Weighing Accuracy & Stable Performance Dual‑speed coarse‑fine feeding, weighing accuracy ±0.5%‑1%. Adopts anti‑vibration weighing sensor, zero‑tracking & automatic compensation function, stable for long‑time continuous production.

✅ Dust‑Sealed Filling Structure Flexible sealed filling nozzle connects tightly with ton‑bag opening. Reserved dust‑removing interface to connect dust collector, reduce floating dust, improve workshop environment and reduce material waste.

✅ High‑Degree Automation, Labor Saving Only one worker is needed for bag hanging operation. PLC touch‑screen operation, store multiple groups of weight parameters, quick switch for different ton‑bag specifications. Support auto/manual dual modes.

✅ Wide Material Compatibility Perfect for wood pellets, straw pellets, rice husk pellets, palm kernel pellets and other biomass granular fuels. Suitable for 500kg‑2000kg FIBC jumbo bags.

✅ Solid Industrial‑Grade Structure & Easy Maintenance Heavy‑duty carbon steel frame, parts contacting material adopt wear‑resistant treatment. Modular design, easy access for inspection and replacement of wearing parts, low daily maintenance cost.

✅ Perfect Matching for Biomass Pellet Line Can be used as single unit or integrated into full‑turnkey biomass pellet plant. Compatible with crushers, dryers, coolers and conveying systems.

Technical Parameters

表格

Note: Customized design available for special capacity and site condition.

Our Supply Scope

Big‑bag filler main frame, weighing sensor assembly, pneumatic bag‑hooking & clamping mechanism, PLC control cabinet. Optional accessories: roller conveyor, dust collector, material buffer hopper. Service: 12‑month machine warranty, overseas installation guidance, lifelong spare‑parts supply, remote technical support.

Get Quote: Tell us your target bag weight, hourly output and site condition, our engineer provides professional solution.
