Comprehensive Crusher

PRODUCT PARAMETERS

  • Model: GLT2000-1000/GLT1600-600/GLT1400-600/GLT1250-600
  • roller diameter (mm): 1400/800/800/800
  • Number of tiger PAWS: 42/28/24/20
  • Knife qty (piece): 2-4
  •  Knife roller speed (RPM): 920/800/800/540
  • Output capacity (t/h): 25-50/20-30/18-25/15-20
  • Dimensions size (mm): 14600x3800x3475/8600×2680×2800/8600×2480×2800/8300×2300×2900
Description
FAQs
Request A Quote

Description

The integrated crusher can process a wide range of raw materials, including wood such as various small-diameter logs, veneer, strips, log cores, and construction templates, as well as various non-wood materials such as bulk straw, cotton stalks, and reeds. It features a chain-plate intelligent feeding system that automatically adjusts the feeding speed according to the main motor load. This ensures full-load operation and avoids idling, resulting in smoother feeding and significantly increased production capacity, making it an ideal choice for biomass power plants.

Model2000‑10001600‑8001400‑6001300-600
roller diameter (mm)1000800600600
Number of tiger PAWS42 28 24 20
Knife qty (piece)4‑84‑83-63-6
Knife roller speed (RPM)600600600600
Length of wood chips (mm)20-5020-5020-5020-50
Main motor power (kw)315/355250/280185/200132/160
Output capacity (t/h)20-3018-2512-1810-15
Dimensions size (mm)14600x3800x34758600×2680×28008600×2480×28008300×2300×2900

FAQs

Our pellet mill processes wood sawdust, wood chips, straw, rice husk, peanut shell, bamboo dust, fruit tree branches and other biomass waste. Different dies are available for various feedstock. Raw materials should be crushed to 3‑5 mm with moisture 10‑15% for premium‑quality pellets. A dryer is required for high‑moisture materials.

o prepare an accurate proposal, please provide:

1.raw material type; 2. target output per hour; 3.raw‑material moisture; 4. local voltage & frequency; 5. workshop size; 6.budget.

Our engineers supply equipment list, layout drawing and budget for free. Material test is available at our factory.

Yes. Motors can be customized to match local voltage & frequency (380V/415V/440V, 50Hz/60Hz) for different countries.

We are direct manufacturer with full‑set machining & assembly workshop. Factory visits are warmly welcome; virtual video tour is available. Material test run is supported.

Common wear parts are in stock and can be shipped together with main machine. For separate orders: air freight 7‑15 days, sea freight 30‑45 days.
